Description
Make: Akcome Solar
Recommended max. PV power: 45 kW
Max. input voltage 1100 V
Rated voltage 600 V
Start-up voltage 180 V
MPPT voltage range 200-1000 V
Max. input current 32 A / 32 A / 32 A 4*32 A
Max. short circuit current 50 A / 50 A / 50 A 4*50 A
MPPT number/Max. input strings number 3/6
Rated output power 30 kW
Max. apparent output power 33 kVA
Max. output power 27.5 kW 33 kW
Rated grid voltage 3/N/PE, 220 V 380 V, 230 V / 400 V
Rated grid frequency 50 Hz / 60 Hz
Rated grid output current 45.6 A / 43.3 A
Max. output current: 50.2 A
Power Factor: >0.99 (0.8 leading – 0.8 lagging)
THDi: <3%
Download Data Sheet Solis 30kw
Key features:
- Max. efficiency 98.7%
- String current up to 16A
- 3/4 MPPT design, supports multiple orientation system design
- Night time PID recovery function, increases overall system yield (optional)
- Wide voltage range and low startup voltage
- Supports export power control
- Intelligent string monitoring, smart I-V curve scan
- Supports RS485, WiFi, GPRS
- Scan to register on SolisCloud, supports remote upgrade and control
